image ECOFLEX SYSTEM: HUMIDITY AND TEMPERATURE CONTROL SUBSYSTEM
ECOFLEX SYSTEM: HUMIDITY AND TEMPERATURE CONTROL SUBSYSTEM

Considering humidity and temperature at industrial enterprises (especially food industry enterprises) is extremely important to ensure stable conditions for the production and storage of products, their safety, functioning of refrigeration and climatic equipment verifying.

We offer you an integrated subsystem for monitoring the humidity and temperature of industrial premises by EcoFlex system, which is a functionality extension of the standard system, allowing you to conduct operational monitoring of these parameters and a database of temperature and humidity values ​​in a particular room and/or equipment (for example, refrigeration and climatic cameras).

Data is transmitted to the central server via standard channels of the common system from digital temperature and humidity sensors via Modbus protocol and wired RS485 interface. The frequency of polling sensors is configured in the system. This approach allows us to solve three problems – direct operational control of humidity and temperature, notification of deviations of parameters matching established limits, as well as the ability to archive and analyze temperature and humidity.

Temperature and humidity sensor

  • Dimensions: 72mm x 44mm x 22m
  • Temperature accuracy: 0.5 ° C
  • Measuring range: -55 .. +125 ° С
  • Humidity Measurement Accuracy: 2-5%
  • Measured humidity range: 0 … 100%
  • Digital Interface: RS-485
  • Analog output (temperature): 0..10V
  • Supply voltage: 9 .. 24V
  • Power Consumption: 0.25 W



Estimated cost of connecting one temperature sensor (considering software and equipment costs, excluding installation materials cost) – about 2000-2500 UAH. without VAT
